Product Description
Thermosyphon solar heating systems based on flat plate solar collector provides a simple way to get hot water from the sun.
A normal-working system requires neither pump nor temperature- differential-control, the systems are very easy installation, simple and low cost maintenance.
All systems equipped with high- efficiency solar collectors, pressurized water tanks, and accessories pack for easy installation.
Thermosyphon systems are always smart choices for harvesting hot water from the sun and saving our heating cost.
- System Volume available: 150L / 260L / 320L.
- Both of inner and outer cover of tank is made of SUS304 high-grade stainless steel.
- Strong mounting frame for flat roof or pitch roof mounting.
- Easy installation and maintenance.
- Full automatic controller.
- Automatic start / stop the auxiliary electric heater under preset timing and temperature level.
- With Back up electric heater, ensure adequate hot water supplying at rainy or cloudy days.
SPECIFICATION AND PRICE QUOTATION
| PART | Model | TH-150-A2.0 | TH-250-A4.0 | TH-300-A4.0 |
| Water Storage | Capacity | 150 Liters | 250 Liters | 300 Liters |
| | Ext. Size(mm) | Φ560x 970 | Φ520 x 1870 | Φ560 x 1870 |
| Tank | Inner material | SUS304 2B | SUS304 2B | SUS304 2B |
| | 1.2mm | 1.5mm | 1.5mm |
| | Tank out cover material | SUS304 2B/1.0mm |
| | Insulation | High density polyurethane |
| | Tank out cover material | SUS304 2B |
| 2.Solar Collector | Collector Model* | A/C/E Series (Optional) |
| Collector Size(mm) | 2000x1000x78 |
| Collector quantity | 1 x 2.0M2 | 2 x 2M2 | 2 x 2M2 |
| Total Collector Area | 2.4M2 | 4M2 | 4 M2 |
| 3.Mounting Stand | Aluminum alloy mounting stand for flat roof * 1SET |
| Fitting and pipe | Brass fitting / Valve / PEX circulation pipe * 1set |
|
| 4.Controller | YN388 | Full automatic intelligent system controller * 1ET |
| (Optional) |
| Auxiliary Electric Heater | 1.5KW | 2KW | 3KW |
| |
| (Optional) |
| 20' container loading quantity | 40 Sets | 30 Sets | 25 Sets |
